5314 NTN

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 150
3. Width (B) MM 63,5
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 5.9055
6. Width (B) Inch 2.5

Technical details

1. Availability 2 pcs
2. Brand NTN
3. Item number 5314 NTN
4. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 4.89

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard
