5206CLLU/2AS NTN

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 62
3. Width (B) MM 23,8
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.937

Suffix description

1. C 15° Contact Angle
2. LLU Rubber Seals At Each Side Of The Bearing
3. 2AS Lubricant, Shell Oil Co., Alvania #2 Grease, Mil-G-18709A

Technical details

1. Availability 33 pcs
2. Brand NTN
3. Item number 5206CLLU/2AS NTN
4. Also known as 5206 2RS
   5206A-2RS1

5. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.289

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard
