47686/47620 ZKL

Single-row tapered roller bearing

Stock
not in stock
Brand ZKL
Article number 47686/47620 ZKL
Inside diameter 82,55mm
Outside diameter 133,35mm
Width 33,34mm
Product description

The 47686/47620 ZKL is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.

The 47686/47620 ZKL is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.

Help with this product

Similar to: 47686/47620 ZKL

Product
Dimensions/Properties
Stock
Price ex VAT
47686/47620 Timken
47686/47620 Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)
164,02 ex VAT
  • Inside diameter 82,55mm
  • Outside diameter 133,35mm
  • Width 33,34mm
47686/47620 Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)

5 pcs
164,02 ex VAT
SET411-900SA Timken
SET411-900SA Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)
164,02 ex VAT
SET411-900SA Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)

9 pcs
164,02 ex VAT
47686/47620 Tyson
47686/47620 Tyson
Guaranteed same day shipment on orders placed before 18:00h (CET)
70,82 ex VAT
  • Inside diameter 82,55mm
  • Outside diameter 133,35mm
  • Width 33,34mm
47686/47620 Tyson
Guaranteed same day shipment on orders placed before 18:00h (CET)

10 pcs
70,82 ex VAT
4T-47686/47620 NTN
4T-47686/47620 NTN
Guaranteed same day shipment on orders placed before 18:00h (CET)
63,04 ex VAT
4T-47686/47620 NTN
Guaranteed same day shipment on orders placed before 18:00h (CET)

1 pc
63,04 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 82,55
  2. Outer (D) MM 133,35
  3. Width (B) MM 33,34
  4. Inner (d) Inch 3.25
  5. Outer (D) Inch 5.25
  6. Width (B) Inch 1.3125

Technical details

  1. Availability 0 pcs
  2. Brand ZKL
  3. Item number 47686/47620 ZKL
  4. Also known as 47686/620
    SET411
  5. Category Tapered Roller Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 1.69

Product Properties

  1. Precision Standard Precision
