4206B TN NKE

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 62
3. Width (B) MM 20
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.7874

Suffix description

1. B Design Without Filling Slots Have Contact Angles Of 32°
2. TN Injection Moulded Cage Of Glass Fibre Reinforced Polyamide 6,6, Rolling Element Centered

Technical details

1. Availability 0 pcs
2. Brand NKE
3. Item number 4206B TN NKE
4. Category Deep Groove Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.285

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
