3MM9308WICRDUL Fafnir

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 62
3. Width (B) MM 24
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.9449

Suffix description

1. WI Low Shoulder On Outer Ring
2. CR Phenolic Retainer (Composition) Fafnir Standard
3. DUL Duplex Pair Of Bearings, Universally Ground, Light Preload

Technical details

1. Availability 50 pcs
2. Brand Fafnir
3. Item number 3MM9308WICRDUL Fafnir
4. Also known as 71908ACD/P4ADGA
   B71908-E-T-P4S-DUL

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.22

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
7. Lubrication Standard Lubrication
