3MM9103WI CR DUM Fafnir

All dimensions

1. Inner (d) MM 17,00
2. Outer (D) MM 35,00
3. Width (B) MM 20,00
4. Inner (d) Inch 0.6693
5. Outer (D) Inch 1.3780
6. Width (B) Inch 0.7874

Suffix description

1. 2MM 15° Low Contact Angle, Superprecision ABEC-7 (ISO P4),
2. 3MM 25° High Contact Angle Superprecision ABEC-7 (ISO P4),
3. 2MMV 15° Low Contact Angle, High Grade (HG) Between ABEC-7 (ISO P4) And ABEC-9 (ISO P2),
4. 3MMV 25° High Contact Angle, High Grade (HG) Between ABEC-7 (ISO P4) and ABEC-9 (ISO P2)
5. WI Low Shoulder On Outer RIng (Standard Cage!!! (Molded Reinforced Nylon Cage))
6. CR (TB-SEGMENT) PHENOLIC (COMPOSITION) FAFNIR STANDARD
7. DUM duplex pair of bearings, universally ground, medium preload

Technical details

1. Availability 0 pcs
2. Brand Fafnir
3. Item number 3MM9103WI CR DUM Fafnir
4. Also known as 7003ACD/P4ADGB
   B7003-E-T-P4S-DUM

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.074

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 25 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DM - 2 Univ Bearings Medium Pre
7. Lubrication Standard Lubrication
