39528/Q SKF

Cup for single-row tapered roller bearing

Stock
4 pcs in stock and ready for shipment
Brand SKF
Article number 39528/Q SKF
Outside diameter 119,985mm
Width 26,9494mm
Product description

The 39528/Q SKF is a cup for a single-row tapered roller bearing. This cup is an outer ring that can be combined with a separately available cone (the cage with rolling elements), to form a complete tapered roller bearing. The outer and inner rings have conical raceways and the roller elements are conical as well. This design enables tapered roller bearings to absorb radial and axial forces (in one direction). The greater the angle between the outer ring and the centre line of the bearing, the greater the axial load capacity.

The geometrical qualities of tapered roller bearings prevent sliding movements between the raceways and rollers. This will keep component wear down to a minimum. However, a minimum load is required for proper bearing operation. Because cone and cup are separable, they can easily be mounted. In addition, end play (axial clearance) or preload can be adjusted by moving the components axially during assembly.

For reliable operation of your bearing, it is best to replace cone and cup at the same time. We recommend taking components from the same manufacturer. This prevents bearing problems caused by different internal bearing profiles, differences in material, and in tolerances. Always combine the 39528/Q SKF with a matching cone from the same manufacturer.

Read more Show less
Help with this product

Similar to: 39528/Q SKF

Product
Dimensions/Properties
Stock
Price ex VAT
39528 Timken
39528 Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)
60,75 ex VAT
  • Inside diameter 0mm
  • Outside diameter 119,985mm
  • Width 26,9494mm
39528 Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)

14 pcs
60,75 ex VAT

Product specifications

All dimensions

  1. Outer (D) MM 119,985
  2. Width (B) MM 26,9494
  3. Outer (D) Inch 4.7238
  4. Width (B) Inch 1.061

Suffix description

  1. Q TQ-Line Execution. (100% Interchangeable With Basic Designation)

Technical details

  1. Availability 4 pcs
  2. Brand SKF
  3. Item number 39528/Q SKF
  4. EAN 7316571180984
  5. Category Cup for Tapered Roller Bearings Single Row

Weight and Dimensions

  1. Weight (kg) 0.7
