394980A-2Z SKF

All dimensions

1. Inner (d) MM 0,5
2. Outer (D) MM 1,125
3. Width (B) MM 0,3125
4. Inner (d) Inch 0.0197
5. Outer (D) Inch 0.0443
6. Width (B) Inch 0.0123

Suffix description

1. A Deviating Or Modified Internal Design With Same Boundary Dimensions. As A Rule The Significance Of The Letter Is Bound To The Particular Bearing Or Bearing Series
2. 2Z Two Metallic Shields

Technical details

1. Availability 3 pcs
2. Brand SKF
3. Item number 394980A-2Z SKF
4. Also known as R8-2Z

5. EAN 7316570064735
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.018

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
