3804-B-2RSR-TVH-HLC FAG

Angular Contact Ball Bearing Double Row

Stock
139 pcs in stock and ready for shipment
Brand FAG
Article number 3804-B-2RSR-TVH-HLC FAG
Inside diameter 20mm
Outside diameter 32mm
Width 10mm
Product description

The 3804-B-2RSR-TVH-HLC FAG is a double row angular contact ball bearing with solid inner- and outer rings. The design of this bearing type resembles two single row angular contact ball bearings in O-arrangement but is slightly narrower. Also, the contact angle and the design of the bearing rings are different. double row angular contact ball bearings can support high radial forces and axial forces in both directions. The greater the contact angle, the greater the axial load capacity of the bearing.

Read more Show less
Help with this product

Downloads and links

Similar to: 3804-B-2RSR-TVH-HLC FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 20
  2. Outer (D) MM 32
  3. Width (B) MM 10
  4. Inner (d) Inch 0.7874
  5. Outer (D) Inch 1.2598
  6. Width (B) Inch 0.3937
  7. Width (b) mm 10

Suffix description

  1. B Internal Design Modification
  2. 2RSR Seal At Each Side Of The Bearing
  3. TVH Moulded Polyamide Cage Snap-Type, Rolling Element Riding
  4. HLC Factory Location Code, No Additional Meaning, Can Be Used As Standard

Technical details

  1. Availability 139 pcs
  2. Brand FAG
  3. Item number 3804-B-2RSR-TVH-HLC FAG
  4. Also known as 0797272710000
  5. EAN 4047643134002
  6. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

  1. Weight (kg) 0.024

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal 2RS - Rubber Seal on Two Sides
  3. Cage Type P - Plastic Molded Cage
  4. External Modification No External Modification
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision Standard Precision
  7. Lubrication Standard Lubrication
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 4750
  2. Radial Dynamic Load Rating Cr (N) 5600
  3. Limiting speed (n G) 10600
  4. ECLASS number 23-05-08-03
  5. ECLASS2 number 23-05-08-03
  6. Medias description Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25°

Downloads and links

  1. Link to manufacturer Link to manufacturer
