3802-B-2RSR-TVH-HLC FAG

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 24
3. Width (B) MM 7
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 0.9449
6. Width (B) Inch 0.2756
7. Width (b) mm 7

Suffix description

1. B Internal Design Modification
2. 2RSR Seal At Each Side Of The Bearing
3. TVH Moulded Polyamide Cage Snap-Type, Rolling Element Riding
4. HLC Factory Location Code, No Additional Meaning, Can Be Used As Standard

Technical details

1. Availability 44 pcs
2. Brand FAG
3. Item number 3802-B-2RSR-TVH-HLC FAG
4. Also known as 0725293000000
   3802-B-2RSR-TVH

5. EAN 4012802774450
6. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.009

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 1920
2. Radial Dynamic Load Rating Cr (N) 2380
3. Limiting speed (n G) 14700
4. ECLASS number 23-05-08-03
5. ECLASS2 number 23-05-08-03
6. Medias description Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25°
