3312-B-2Z-TVH-C3 FAG

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 130
3. Width (B) MM 54
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 5.1181
6. Width (B) Inch 2.126

Suffix description

1. B Internal Design Modification
2. 2Z Shields At Both Sides Of The Bearing
3. TVH Moulded Polyamide Cage Snap-Type, Rolling Element Riding
4. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 10 pcs on Mon 23 Jun
2. Brand FAG
3. Item number 3312-B-2Z-TVH-C3 FAG
4. Also known as 0861325040030
   3312-2Z-C3

5. EAN 4064328013032
6. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 2.9298

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard
