3309A/C3W64 SKF

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 100
3. Width (B) MM 39,7
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.937
6. Width (B) Inch 1.563

Suffix description

1. A Double Row Angular Contact Ball Bearing Without Filling Slots
2. C3 Internal Clearance Larger Than Normal
3. W64 Solid Oil Filling

Technical details

1. Availability 0 pcs
2. Brand SKF
3. Item number 3309A/C3W64 SKF
4. EAN 7316572569467
5. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 1.3

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Filled Solid Grease
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard
