32234-XL-DF-A350-410 FAG

All dimensions

1. Inner (d) MM 170
2. Outer (D) MM 310
3. Width (B) MM 182
4. Inner (d) Inch 6.6929
5. Outer (D) Inch 12.2047
6. Width (B) Inch 7.1654
7. Inner ring total width (2B) mm 172
8. Outer ring total width (2T) mm 182

Suffix description

1. XL X-Life
2. DF Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
3. A350-410 Axial Clearance In µm

Technical details

1. Availability 3 pcs
2. Brand FAG
3. Item number 32234-XL-DF-A350-410 FAG
4. Also known as 0867416674081
   32234-DF-A350-410

5. EAN 4054369349511
6. Category Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

1. Weight (kg) 59.2

Product Properties

1. Tapered Roller Pair Internal Play 350-410µm

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 3100000
2. Radial Dynamic Load Rating Cr (N) 1980000
3. Limiting speed (n G) 2350
4. Thermal speed rating (n ϑr) 1090
5. ECLASS number 23-05-09-10
6. ECLASS2 number 23-05-09-10
7. Medias description Tapered roller bearing set 322..-XL-DF, X-arrangement
