3208A-2RS1TN9/MT33 SKF

Double row angular contact ball bearing

Stock
13 pcs in stock and ready for shipment
Brand SKF
Article number 3208A-2RS1TN9/MT33 SKF
Inside diameter 40mm
Outside diameter 80mm
Width 30,2mm
Product description

The 3208A-2RS1TN9/MT33 SKF is a double-row angular contact ball bearing with solid inner- and outer rings. The design of this bearing type resembles two single-row angular contact ball bearings in O-arrangement but is slightly narrower. Double-row angular contact ball bearings can support high radial forces and axial forces in both directions. The greater the contact angle, the greater the axial load capacity of the bearing.

Read more Show less
Help with this product

Similar to: 3208A-2RS1TN9/MT33 SKF

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 40
  2. Outer (D) MM 80
  3. Width (B) MM 30,2
  4. Inner (d) Inch 1.5748
  5. Outer (D) Inch 3.1496
  6. Width (B) Inch 1.189

Suffix description

  1. A Double Row Angular Contact Ball Bearing Without Filling Slots
  2. 2RS1 Sheet Steel Reinforced Contact Seal Of Acrylonitrile-Butadiene Rubber (NBR) On Both Sides Of The Bearing
  3. TN9 Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered
  4. MT33 Lithium Grease, Medium Temp. 74 cSt @ 40°C, -30°C/+120°C, A Two-Figure Number Following MT Identifies The Actual Grease. An Additional Letter Or Letter/Figure Combination As Mentioned Under "HT" Identifies Filling Degrees Other Than Standard. Examples: MT33 Or MT37F9

Technical details

  1. Availability 13 pcs
  2. Brand SKF
  3. Item number 3208A-2RS1TN9/MT33 SKF
  4. Also known as 3208A-2RS1TN9
  5. EAN 7316570484588
  6. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

  1. Weight (kg) 0.585

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal 2RS - Rubber Seal on Two Sides
  3. Cage Type P - Plastic Molded Cage
  4. External Modification No External Modification
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision Standard Precision
  7. Lubrication M - Grease with Lithium Thickener
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Split Inner ring / Outer ring Standard
