3206ATN9/C3 SKF

Double row angular contact ball bearing

Stock
26 pcs in stock and ready for shipment
Brand SKF
Article number 3206ATN9/C3 SKF
Inside diameter 30mm
Outside diameter 62mm
Width 23,8mm
Product description

The 3206ATN9/C3 SKF is a double-row angular contact ball bearing with solid inner- and outer rings. The design of this bearing type resembles two single-row angular contact ball bearings in O-arrangement but is slightly narrower. Double-row angular contact ball bearings can support high radial forces and axial forces in both directions. The greater the contact angle, the greater the axial load capacity of the bearing.

Help with this product

Similar to: 3206ATN9/C3 SKF

Product
Dimensions/Properties
Stock
Price ex VAT
3206-BD-XL-TVH-C3 FAG
3206-BD-XL-TVH-C3 FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)
26,94 ex VAT
  • Inside diameter 30mm
  • Outside diameter 62mm
  • Width 23,8mm
3206-BD-XL-TVH-C3 FAG
Guaranteed same day shipment on orders placed before 18:00h (CET)

17 pcs
26,94 ex VAT
3206-B-TV-C3 NKE
3206-B-TV-C3 NKE
Guaranteed same day shipment on orders placed before 18:00h (CET)
18,46 ex VAT
  • Inside diameter 30mm
  • Outside diameter 62mm
  • Width 23,8mm
3206-B-TV-C3 NKE
Guaranteed same day shipment on orders placed before 18:00h (CET)

2 pcs
18,46 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 62
  3. Width (B) MM 23,8
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 2.4409
  6. Width (B) Inch 0.937

Suffix description

  1. A Double Row Angular Contact Ball Bearing Without Filling Slots
  2. TN9 Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered
  3. C3 Internal Clearance Larger Than Normal

Technical details

  1. Availability 26 pcs
  2. Brand SKF
  3. Item number 3206ATN9/C3 SKF
  4. EAN 7316577039743
  5. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

  1. Weight (kg) 0.28

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal No Seal
  3. Cage Type P - Plastic Molded Cage
  4. External Modification No External Modification
  5. Radial Internal Play C3 Internal Play (Higher than Cn)
  6. Precision Standard Precision
  7. Lubrication Standard Lubrication
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Split Inner ring / Outer ring Standard
