32044-X-XL-DF-A400-450 FAG

All dimensions

1. Inner (d) MM 220
2. Outer (D) MM 340
3. Width (B) MM 152
4. Inner (d) Inch 8.6614
5. Outer (D) Inch 13.3858
6. Width (B) Inch 5.9843
7. Inner ring total width (2B) mm 152
8. Outer ring total width (2T) mm 152

Suffix description

1. X External Dimensions Matched To International Standards
2. XL X-Life
3. DF Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
4. A400-450 Axial Clearance In µm

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 32044-X-XL-DF-A400-450 FAG
4. Also known as 0850164464081
   32044
   32044-X
   32044-X-DF-A400-450

5. EAN 4054364838683
6. Category Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

1. Weight (kg) 50

Product Properties

1. Tapered Roller Pair Internal Play 400-450µm

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 3300000
2. Limiting speed (n G) 2080
3. Thermal speed rating (n ϑr) 920
