32040-X-XL-DF-A350-400 FAG

All dimensions

1. Inner (d) MM 200
2. Outer (D) MM 310
3. Width (B) MM 140
4. Inner (d) Inch 7.874
5. Outer (D) Inch 12.2047
6. Width (B) Inch 5.5118
7. Inner ring total width (2B) mm 140
8. Outer ring total width (2T) mm 140

Suffix description

1. X External Dimensions Matched To International Standards
2. XL X-Life
3. DF Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
4. A350-400 Axial Clearance In µm

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 32040-X-XL-DF-A350-400 FAG
4. Also known as 0851510174080
   32040
   32040-X
   32040-X-DF-A350-400

5. EAN 4054364753986
6. Category Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

1. Weight (kg) 38.5

Product Properties

1. Tapered Roller Pair Internal Play 350-400µm

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 2750000
2. Limiting speed (n G) 2290
3. Thermal speed rating (n ϑr) 1060

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
