32021-X-XL-DF-A280-330 FAG

All dimensions

1. Inner (d) MM 105
2. Outer (D) MM 160
3. Width (B) MM 70
4. Inner (d) Inch 4.1339
5. Outer (D) Inch 6.2992
6. Width (B) Inch 2.7559
7. Inner ring total width (2B) mm 70
8. Outer ring total width (2T) mm 70

Suffix description

1. X External Dimensions Matched To International Standards
2. XL X-Life
3. DF Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
4. A280-330 Axial Clearance In µm

Technical details

1. Availability 2 pcs
2. Brand FAG
3. Item number 32021-X-XL-DF-A280-330 FAG
4. Also known as 0870020354080
   32021
   32021-X

5. EAN 4054369225327
6. Category Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

1. Weight (kg) 5.11

Product Properties

1. Tapered Roller Pair Internal Play 280-330µm

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 660000
2. Limiting speed (n G) 4650
3. Thermal speed rating (n ϑr) 2650

Downloads and links

1. X-life brochure X-life brochure
