30/7-2Z-HLC INA

All dimensions

1. Inner (d) MM 7
2. Outer (D) MM 19
3. Width (B) MM 10
4. Inner (d) Inch 0.2756
5. Outer (D) Inch 0.748
6. Width (B) Inch 0.3937
7. Width (b) mm 10

Suffix description

1. 2Z Gap Seals At Both Sides Of The Bearing
2. HLC Factory Location Code, No Additional Meaning, Can Be Used As Standard

Technical details

1. Availability 19 pcs
2. Brand INA
3. Item number 30/7-2Z-HLC INA
4. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.009

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 1690
2. Limiting speed (n G) 29500
3. Reference speed (n ϑr) 31500
