2MMV9107WI CR DUM Fafnir

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 62
3. Width (B) MM 28
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.4409
6. Width (B) Inch 1.1024

Suffix description

1. WI Low Shoulder On Outer Ring
2. CR Phenolic Retainer (Composition) Fafnir Standard
3. DUM Duplex Pair Of Bearings, Universally Ground, Medium Preload

Technical details

1. Availability 1 pc
2. Brand Fafnir
3. Item number 2MMV9107WI CR DUM Fafnir
4. Also known as 7007CD/P4ADGB
   B7007-C-T-P4S-DUM

5. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.3

Product Properties

1. Seal No Seal
2. Cage Type TB - Hard Fiber Cage
3. Precision P4 Precision (Higher than P5)
4. Contact Angle 15 degrees
5. Pairing G - Universal Pairing
6. Axial Internal Clearance / Preload DM - 2 Univ Bearings Medium Pre
7. Lubrication Standard Lubrication
