29480-E1-XL-MB FAG

All dimensions

1. Inner (d) MM 400,00
2. Outer (D) MM 710,00
3. Width (B) MM 185,00
4. Inner (d) Inch 15.7480
5. Outer (D) Inch 27.9528
6. Width (B) Inch 7.2835
7. Section height (T) mm 185,00

Suffix description

1. E1 Increased Capacity Design
2. XL X-Life
3. MB Two-Piece Solid Brass Cage, Guided On Central Rib

Technical details

1. Availability 1 pc
2. Brand FAG
3. Item number 29480-E1-XL-MB FAG
4. Also known as 0390007100000
   29480-E1-MB

5. EAN 4012802190823
6. Category Spherical Roller Thrust Bearing

Weight and Dimensions

1. Weight (kg) 286

Product Properties

1. Cage Type M - Brass Cage

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) "8200000.0000"
2. Axial Static Load Rating C0a (N) 26500000
3. Basic static load rating, axial (C 0a) "26500000.0000"
4. Axial Dynamic Load Rating Ca (N) 8200000
5. Limiting speed (n G) "870.0000"
6. Reference speed (n ϑr) "425.0000"
7. ECLASS number 23-05-11-03
8. ECLASS2 number 23-05-11-03
9. Medias description Axial spherical roller bearing 294..-E1-XL-MB, with flanging ring
