29322-E1-XL-N1 FAG

All dimensions

1. Inner (d) MM 110,00
2. Outer (D) MM 190,00
3. Width (B) MM 48,00
4. Inner (d) Inch 4.3307
5. Outer (D) Inch 7.4803
6. Width (B) Inch 1.8898
7. Height (T) mm 48,00

Suffix description

1. E1 Increased Capacity Design
2. XL X-Life
3. N1 One Locating Slot In Outside Edge Of Outer Ring (For Radial Location Of The Bearing)

Technical details

1. Availability 4 pcs
2. Brand FAG
3. Item number 29322-E1-XL-N1 FAG
4. Also known as 0389997650000
   29322-E1-N1

5. EAN 4012802189872
6. Category Spherical Roller Thrust Bearing

Weight and Dimensions

1. Weight (kg) 5.04

Product Properties

1. Cage Type S - Steel or Standard Cage

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) "620000.0000"
2. Axial Static Load Rating C0a (N) 1760000
3. Basic static load rating, axial (C 0a) "1760000.0000"
4. Axial Dynamic Load Rating Ca (N) 620000
5. Limiting speed (n G) "3750.0000"
6. Reference speed (n ϑr) "1830.0000"
7. ECLASS number 23-05-11-03
8. ECLASS2 number 23-05-11-03
9. Medias description Axial spherical roller bearing 293..-E1-XL, no flanging ring
