28BWD03ACA51 NSK

All dimensions

1. Inner (d) MM 28
2. Outer (D) MM 58
3. Width (B) MM 42
4. Inner (d) Inch 1.1024
5. Outer (D) Inch 2.2835
6. Width (B) Inch 1.6535

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 28BWD03ACA51 NSK
4. Also known as DAC28582RKCS47

5. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.47

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Split Inner ring / Outer ring Standard
