234710-M-SP FAG

All dimensions

1. Inner (d) MM 52
2. Outer (D) MM 80
3. Width (B) MM 38
4. Inner (d) Inch 2.0472
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.4961

Suffix description

1. M Solid Brass Cage, Ball-Guided
2. SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 234710-M-SP FAG
4. Also known as 0384398320000

5. EAN 4012801488020
6. Category Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

1. Weight (kg) 0.408

Product Properties

1. Cage Type M - Brass Cage
2. Precision SP - Precision Higher than P4S

Data from Schaeffler (medias)

1. ECLASS number 23-05-10-02
2. ECLASS2 number 23-05-10-02

Downloads and links

1. Link to manufacturer Link to manufacturer
