23236-E1-XL-TVPB FAG

The 23236-E1-XL-TVPB FAG bearing is a spherical roller bearing with a plastic molded cage, a cylindrical bore and no seal.

Stock
not in stock
Brand FAG
Article number 23236-E1-XL-TVPB FAG
Inside diameter 180mm
Outside diameter 320mm
Width 112mm
Product description
Spherical Roller Bearing
Read more Show less

Similar to: 23236-E1-XL-TVPB FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 180
  2. Outer (D) MM 320
  3. Width (B) MM 112
  4. Inner (d) Inch -
  5. Outer (D) Inch -
  6. Width (B) Inch -

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number 23236-E1-XL-TVPB FAG
  4. Technical details (E1-XL-TVPB) Series 241... Have A Brass Cage Standard, Series 241..-E1 Have A Steel Cage Standard. E1=Increased Capacity Design. XL=X-Life. TVPB=Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring.
  5. Also known as 23236-E1-TVPB
    4026677845825
  6. Category Spherical Roller Bearing
  7. Weight (kg) 37.85
  8. Manufacturer Part Number (MPN) 23236-E1-XL-TVPB
  9. Bore C - Cylindrical Bore
  10. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
  11. Seal No Seal
  12. Cage Type P - Plastic Molded Cage
  13. Radial Internal Play Cn Normal Internal
  14. Precision Standard Precision
  15. Heat Stabilization No Heat Stabilization - Temperatures up to 120°C
  16. Vibrating Screen Execution No Vibratory Screen Execution
