2320M FAG

Double-row self-aligning ball bearing without seal

Stock
not in stock
Brand FAG
Article number 2320M FAG
Inside diameter 100mm
Outside diameter 215mm
Width 73mm
Product description

The 2320M FAG belongs to the group of double-row self-aligning deep-groove ball bearings. This bearing type without a seal is a double-row bearing. Both rows are housed in a spherical raceway in the outer ring. This construction allows the bearing to be self-aligning. This means that any misalignment of the shaft relative to the bearing housing does not adversely affect performance.

These features make the 2320M FAG highly suitable for applications where substantial misalignment or shaft deflections may occur. Also, self-aligning bearings have the lowest friction of all rolling-element bearings. Even at higher speeds, there is only limited frictional heat. These bearings are capable of handling high radial loads. To a lesser extent, they can be axially loaded in both directions.

Help with this product

Downloads and links

Similar to: 2320M FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 100
  2. Outer (D) MM 215
  3. Width (B) MM 73
  4. Inner (d) Inch 3.937
  5. Outer (D) Inch 8.4646
  6. Width (B) Inch 2.874

Suffix description

  1. M Solid Brass Cage

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number 2320M FAG
  4. Category Self Aligning Ball Bearing Double Row

Weight and Dimensions

  1. Weight (kg) 12.4

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal No Seal
  3. Cage Type M - Brass Cage
  4. Radial Internal Play Cn Normal Internal Play
  5. Precision Standard Precision
  6. Lubrication Standard Lubrication
  7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
