231SM170-MA FAG

All dimensions

1. Inner (d) MM 170
2. Outer (D) MM 320
3. Width (B) MM 104
4. Inner (d) Inch 6.6929
5. Outer (D) Inch 12.5984
6. Width (B) Inch 4.0945

Suffix description

1. MA Machined Brass Cage, Outer Ring Guided

Technical details

1. Availability 1 pc
2. Brand FAG
3. Item number 231SM170-MA FAG
4. Also known as 0384396030000

5. EAN 4026677204493
6. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 40.5996

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type MA - Brass Cage, Centered on Outer Ring
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
