23140K C3 NTN

All dimensions

1. Inner (d) MM 200
2. Outer (D) MM 340
3. Width (B) MM 112
4. Inner (d) Inch 7.874
5. Outer (D) Inch 13.3858
6. Width (B) Inch 4.4094

Suffix description

1. K Tapered Bore, Taper 1:12
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 0 pcs
2. Brand NTN
3. Item number 23140K C3 NTN
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 42.8

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type S - Steel or Standard Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
