23128EM D1 NTN

All dimensions

1. Inner (d) MM 140
2. Outer (D) MM 225
3. Width (B) MM 68
4. Inner (d) Inch 5.5118
5. Outer (D) Inch 8.8583
6. Width (B) Inch 2.6772

Suffix description

1. E Increased Load Capacity
2. M Machined Brass Cage, Located On The Rolling Elements
3. D1 Lubrication Groove And Three Holes In Bearing Outer Ring. As Of => D320 No D1 Suffix Is Used

Technical details

1. Availability 1 pc
2. Brand NTN
3. Item number 23128EM D1 NTN
4. Also known as 23128-E1A-M
   23128-E1A-XL-M
   23128EMW33

5. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 10.2

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
