23128EKMS CBF

All dimensions

1. Inner (d) MM 140,00
2. Outer (D) MM 225,00
3. Width (B) MM 68,00
4. Inner (d) Inch 5.5118
5. Outer (D) Inch 8.8583
6. Width (B) Inch 2.6772

Suffix description

1. E E-Type, Without Integral Lips At The Inner Ring
2. K Tapered Bore, Taper 1:12
3. M Machined Brass Cage, Located On The Rolling Elements
4. S Lubrication Groove And Three Holes In Bearing Outer Ring

Technical details

1. Availability 0 pcs
2. Brand CBF
3. Item number 23128EKMS CBF
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 9.663

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
