23128CAMKE4S11 NSK

All dimensions

1. Inner (d) MM 140
2. Outer (D) MM 225
3. Width (B) MM 68
4. Inner (d) Inch 5.5118
5. Outer (D) Inch 8.8583
6. Width (B) Inch 2.6772

Suffix description

1. CAM One Piece Brass Cage, Guide Ring
2. K Tapered Bore, Taper 1:12
3. E4 Lubrication Groove And Holes In Bearing Outer Ring
4. S11 Inner And Outer Ring Heat Stabilized To 200°C

Technical details

1. Availability 2 pcs
2. Brand NSK
3. Item number 23128CAMKE4S11 NSK
4. Also known as 23128CAMKE4
   23128-E1A-K-M
   23128-E1A-XL-K-M

5. EAN 00029176529139
6. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 9.663

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
