23128CA C3 W33 Rollway

All dimensions

1. Inner (d) MM 140
2. Outer (D) MM 225
3. Width (B) MM 68
4. Inner (d) Inch 5.5118
5. Outer (D) Inch 8.8583
6. Width (B) Inch 2.6772

Suffix description

1. CA Single Piece, Brass Cage
2. C3 Internal Clearance Larger Than Normal
3. W33 Lubrication Groove And Three Holes In Bearing Outer Ring

Technical details

1. Availability 0 pcs
2. Brand Rollway
3. Item number 23128CA C3 W33 Rollway
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 10.2

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
