23126VK F107 SNR

All dimensions

1. Inner (d) MM 130
2. Outer (D) MM 210
3. Width (B) MM 64
4. Inner (d) Inch 5.1181
5. Outer (D) Inch 8.2677
6. Width (B) Inch 2.5197

Suffix description

1. V Internal Design Modification
2. KF107
3. K (Tapered Bore, Taper 1:12) +
4. M (Machined Brass Cage, Centered On Inner Ring) +
5. C3 (Internal Clearance Larger Than Normal) +
6. W33 (Lubrication Groove And Three Holes In Bearing Outer Ring)

Technical details

1. Availability 0 pcs
2. Brand SNR
3. Item number 23126VK F107 SNR
4. Also known as 23126-E1A-K-M-C3

5. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 8.4

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
