23126CE4C3 NSK

All dimensions

1. Inner (d) MM 130
2. Outer (D) MM 210
3. Width (B) MM 64
4. Inner (d) Inch 5.1181
5. Outer (D) Inch 8.2677
6. Width (B) Inch 2.5197

Suffix description

1. C Two-Piece Pressed Steel Cage With Guide Ring
2. E4 Lubrication Groove And Holes In Bearing Outer Ring
3. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 23126CE4C3 NSK
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 8.11

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type S - Steel or Standard Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
