23124CA C3 W33 RKB

All dimensions

1. Inner (d) MM 120,00
2. Outer (D) MM 200,00
3. Width (B) MM 62,00
4. Inner (d) Inch 4.7244
5. Outer (D) Inch 7.8740
6. Width (B) Inch 2.4409

Suffix description

1. CA Bearings With Symmetrical Rollers And Retaining Ribs. The Cage Is A One-Piece, Double Pronged Machined Cage Of Brass
2. C3 Internal Clearance Larger Than Normal
3. W33 Lubrication Groove And Three Holes In Bearing Outer Ring

Technical details

1. Availability 0 pcs
2. Brand RKB
3. Item number 23124CA C3 W33 RKB
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 7.7

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
