23122CAK C3 W33 ZWZ

All dimensions

1. Inner (d) MM 110
2. Outer (D) MM 180
3. Width (B) MM 56

Suffix description

1. CA Spherical Roller Bearing With Symmetrical Rollers
2. K Tapered Bore Bearing With Taper
3. 1:12.C3 Internal Clearance Larger Than Normal
4. W33 Lubrication Groove And Three Holes In Bearing Outer Ring

Technical details

1. Availability 0 pcs
2. Brand ZWZ
3. Item number 23122CAK C3 W33 ZWZ
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 5.13

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type S - Steel or Standard Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
