23096CAME4S11 NSK

All dimensions

1. Inner (d) MM 480
2. Outer (D) MM 700
3. Width (B) MM 165
4. Inner (d) Inch 18.8976
5. Outer (D) Inch 27.5591
6. Width (B) Inch 6.4961

Suffix description

1. CAM One Piece Brass Cage, Guide Ring
2. E4 Lubrication Groove And Holes In Bearing Outer Ring
3. S11 Inner And Outer Ring Heat Stabilized To 200°C

Technical details

1. Availability 2 pcs
2. Brand NSK
3. Item number 23096CAME4S11 NSK
4. Also known as 23096-BEA-MB1
   23096-BEA-XL-MB1
   23096CA/W33
   23096CAME4
   23096MB
   23096-MB

5. EAN 00192661108307
6. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 222

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
