23080CAMKE4C3S11 NSK

All dimensions

1. Inner (d) MM 400,00
2. Outer (D) MM 600,00
3. Width (B) MM 148,00
4. Inner (d) Inch 15.7480
5. Outer (D) Inch 23.6220
6. Width (B) Inch 5.8268

Suffix description

1. CAM One Piece Brass Cage, Guide Ring
2. K Tapered Bore, Taper 1:12
3. E4 Lubrication Groove And Holes In Bearing Outer Ring
4. C3 Internal Clearance Larger Than Normal
5. S11 Inner And Outer Ring Heat Stabilized To 200°C

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 23080CAMKE4C3S11 NSK
4. Also known as 23080-BEA-XL-K-MB1-C3
   23080CACK/C3W33
   23080CAMKE4C3
   23080-E1A-XL-K-MB1-C3
   23080K.MB.C3
   23080-K-MB-C3
   23080VK B33 M J30

5. EAN 00029176037566
6. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 146

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization S1 - Temperatures up to 200 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
