22334-BEA-XL-K-MB1-C3 FAG

All dimensions

1. Inner (d) MM 170
2. Outer (D) MM 360
3. Width (B) MM 120
4. Inner (d) Inch 6.6929
5. Outer (D) Inch 14.1732
6. Width (B) Inch 4.7244

Suffix description

1. BE Maximum Capacity Design
2. A Modified Internal Construction
3. XL X-Life
4. K Tapered Bore, Taper 1:12
5. MB1 Single-Piece Solid Brass Cage, Guided On Central Rib
6. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 1 pc
2. Brand FAG
3. Item number 22334-BEA-XL-K-MB1-C3 FAG
4. Also known as 0738021150030

5. EAN 4012802863567
6. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 58.2

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
