22313GMEX W33 Rollway

All dimensions

1. Inner (d) MM 65
2. Outer (D) MM 140
3. Width (B) MM 48
4. Inner (d) Inch 2.5591
5. Outer (D) Inch 5.5118
6. Width (B) Inch 1.8898

Suffix description

1. GMEX Improved Precision, Roundness And Surface Finish, Rings And Rollers Are Manufactured In High Grade ROL2 Steel, One Piece Robust Brass Cage, Guided On The Rollers
2. W33 Lubrication Groove And Three Holes In Bearing Outer Ring

Technical details

1. Availability 1 pc
2. Brand Rollway
3. Item number 22313GMEX W33 Rollway
4. Also known as 22313E1A.M
   22313-E1A-M
   22313-E1A-XL-M

5. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 3.54

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
