22312.EF800 NTN

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 130
3. Width (B) MM 46
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 5.1181
6. Width (B) Inch 1.811

Suffix description

1. E Increased Capacity Design, Symmetrical Rollers
2. F800 Bearing With Solid Cage For High-Vibration Applications, Special C4 Clearance

Technical details

1. Availability 0 pcs
2. Brand NTN
3. Item number 22312.EF800 NTN
4. Also known as 22312CAM E4 C4 U15-VS
   22312EMW33W800C4

5. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 2.9098

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Vibrating Screen Execution
