22211KMNW33C3 KFB Clarfeld

All dimensions

1. Inner (d) MM 55
2. Outer (D) MM 100
3. Width (B) MM 25
4. Inner (d) Inch 2.1654
5. Outer (D) Inch 3.937
6. Width (B) Inch 0.9843

Suffix description

1. K Tapered Bore, Taper 1:12
2. M Machined Brass Cage, Located On The Rolling Elements
3. N Snap Ring Groove In The Outer Ring
4. W33 Lubrication Groove And Three Holes In Bearing Outer Ring
5. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 0 pcs
2. Brand KFB Clarfeld
3. Item number 22211KMNW33C3 KFB Clarfeld
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 0.814

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
