2209-K-2RS-TVH FAG

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 85
3. Width (B) MM 23
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.3465
6. Width (B) Inch 0.9055

Suffix description

1. K Tapered Bore, Taper 1:12
2. 2RS Rubber Seals At Each Side Of The Bearing
3. TVH Solid Cage Made From Glass Fibre Reinforced Polyamide 66

Technical details

1. Availability 13 pcs
2. Brand FAG
3. Item number 2209-K-2RS-TVH FAG
4. Also known as 0384725890000
   3002420340000

5. EAN 4026677235848
6. Category Self Aligning Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.545

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type P - Plastic Molded Cage
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Lubrication Standard Lubrication
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Downloads and links

1. Link to manufacturer Link to manufacturer
