20208-TVP FAG

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 80
3. Width (B) MM 18
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.7087
7. Width (b) mm 18

Suffix description

1. TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding

Technical details

1. Availability 17 pcs
2. Brand FAG
3. Item number 20208-TVP FAG
4. Also known as 0167017710000

5. EAN 4012801013949
6. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 0.379

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W - No Lubrication Groove or Holes
3. Seal No Seal
4. Cage Type P - Plastic Molded Cage
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 53000
2. Radial Dynamic Load Rating Cr (N) 49500
3. Limiting speed (n G) 8700
4. ECLASS number 23-05-09-12
5. ECLASS2 number 23-05-09-12
6. Medias description Barrel roller bearings 202, main dimensions to DIN 635-1

Downloads and links

1. Link to manufacturer Link to manufacturer
