16101-A-2Z FAG

Stock
690 pcs in stock and ready for shipment
Brand FAG
Article number 16101-A-2Z FAG
Inside diameter 12mm
Outside diameter 30mm
Width 8mm
Product description
Help with this product

Downloads and links

Similar to: 16101-A-2Z FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 12
  2. Outer (D) MM 30
  3. Width (B) MM 8
  4. Inner (d) Inch 0.4724
  5. Outer (D) Inch 1.1811
  6. Width (B) Inch 0.315
  7. Width (b) mm 8

Suffix description

  1. A Internal Design Modification
  2. 2Z Two Metallic Shields
  3. X10 Industrial Packaging

Technical details

  1. Availability 690 pcs
  2. Brand FAG
  3. Item number 16101-A-2Z FAG
  4. Also known as 0604642160000
  5. EAN 4012802367102
  6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

  1. Weight (kg) 0.028

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal ZZ/2Z - Steel Seal on Two Sides
  3. Cage Type S - Steel or Standard Cage
  4. External Modification No External Modification
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision Standard Precision
  7. Lubrication Standard Lubrication
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 2360
  2. Radial Dynamic Load Rating Cr (N) 5100
  3. Limiting speed (n G) 32500
  4. Reference speed (n ϑr) 25000
  5. ECLASS number 23-05-08-01
  6. ECLASS2 number 23-05-08-01
  7. Medias description Deep groove ball bearing 161..-2Z, single row, cf. DIN 625-1
