16038-MA FAG

All dimensions

1. Inner (d) MM 190
2. Outer (D) MM 290
3. Width (B) MM 31
4. Inner (d) Inch 7.4803
5. Outer (D) Inch 11.4173
6. Width (B) Inch 1.2205
7. Width (b) mm 31

Suffix description

1. MA Machined Brass Cage, Outer Ring Guided

Technical details

1. Availability 4 pcs
2. Brand FAG
3. Item number 16038-MA FAG
4. Also known as 0190116520000

5. EAN 4012801473798
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 7

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type MA - Brass Cage, Centered on Outer Ring
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 168000
2. Radial Dynamic Load Rating Cr (N) 158000
3. Limiting speed (n G) 4050
4. Reference speed (n ϑr) 2650
5. ECLASS number 23-05-08-01
6. ECLASS2 number 23-05-08-01
7. Medias description Deep groove ball bearing 160..-MA, single row, cf. DIN 625-1
