1307TNGP5 NSK

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 80
3. Width (B) MM 21
4. Inner (d) Inch 1.378
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.8268

Suffix description

1. TNG Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
2. P5 Dimensional And Running Accuracy To ISO Tolerance Class 5

Technical details

1. Availability 6 pcs
2. Brand NSK
3. Item number 1307TNGP5 NSK
4. Category Self Aligning Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.51

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. Radial Internal Play Cn Normal Internal Play
5. Precision P5 Precision (Higher than P6)
6. Lubrication Standard Lubrication
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
