1228-M FAG

All dimensions

1. Inner (d) MM 140
2. Inner (d) Inch 5.5118
3. Width (b) mm 50

Suffix description

1. M Solid Brass Cage

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 1228-M FAG
4. Also known as 0190100870000

5. EAN 4012801471152
6. Category Self Aligning Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 11.1

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Lubrication Standard Lubrication
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 74000
2. Radial Dynamic Load Rating Cr (N) 163000
3. Limiting speed (n G) 3900
4. Reference speed (n ϑr) 3650
5. ECLASS number 23-05-08-06
6. ECLASS2 number 23-05-08-06
7. Medias description Self-aligning ball bearings 12, main dimensions to DIN 630

Downloads and links

1. Download datasheet Download datasheet
2. Link to Manufacturer Link to Manufacturer
