1220K.M.C3 FAG

All dimensions

1. Inner (d) MM 100
2. Outer (D) MM 180
3. Width (B) MM 34
4. Inner (d) Inch 3.937
5. Outer (D) Inch 7.0866
6. Width (B) Inch 1.3386

Suffix description

1. K Tapered Bore, Taper 1:12
2. M Solid Brass Cage
3. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number 1220K.M.C3 FAG
4. Category Self Aligning Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 3.94

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Seal No Seal
3. Cage Type M - Brass Cage
4. Radial Internal Play C3 Internal Play (Higher than Cn)
5. Precision Standard Precision
6. Lubrication Standard Lubrication
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Downloads and links

1. Link to manufacturer Link to manufacturer
