1219-M FAG

All dimensions

1. Inner (d) MM 95,00
2. Outer (D) MM 170,00
3. Width (B) MM 32,00
4. Inner (d) Inch 3.7402
5. Outer (D) Inch 6.6929
6. Width (B) Inch 1.2598
7. Width (b) mm 32,00

Suffix description

1. M Solid Brass Cage

Technical details

1. Availability 7 pcs
2. Brand FAG
3. Item number 1219-M FAG
4. Also known as 0190057410000
   1219-M>J
   3001304900000

5. EAN 4012801470865
6. Category Self Aligning Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 3.4

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Lubrication Standard Lubrication
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 27000
2. Radial Dynamic Load Rating Cr (N) 64000
3. Basic static load rating, radial (C 0r) "27000.0000"
4. Limiting speed (n G) "6300.0000"
5. Reference speed (n ϑr) "4600.0000"
6. ECLASS number 23-05-08-06
7. ECLASS2 number 23-05-08-06
8. Medias description Self-aligning ball bearings 12, main dimensions to DIN 630
